Magnetic Non-Contact Safety Interlock Switch (BPR: M18)
IDEMAG are non-contact, magnetic safety switches designed for use on machinery and equipment to ensure the safety of the operators and prevent accidents. The BPR is housed in a red polyester M18 enclosure that is fixed in place via two nuts.
Housed in an M18 Threaded Barrel
2 N/C + 1 N/O Contact Configuration
Sensing Distance up to10mm Operation
Connection via Pre-Wired Cable or M12 Quick Connect
0.5A ac/dc Switching Capacity
Note
Supplied with fixing nuts.
Technical data is taken from the manufacturer's documentation. For safety function sizing, please consult the official data sheet.
Glisați lateral pentru a vedea tot tabelul
| Cod produs | Descriere | Safety | Contacte auxiliare | Conectare |
|---|---|---|---|---|
| 415014 | BPR 5M ‘2NC 1NO’ | 2NC | 1NO | 5M PRE-WIRED |
| 415015 | BPR 10M ‘2NC 1NO’ | 2NC | 1NO | 10M PRE-WIRED |
| 415016 | BPR QC M12 8way ‘2NC 1NO’ | 2NC | 1NO | 250mm Leaded M12 8way |
