Coded Magnetic Non-Contact Safety Interlock Switch
IDECODE Non-Contact safety interlock switches provide a reliable and convenient safety solution for industrial applications, featuring a solid-state design with high switching reliability, voltage-free safety outputs and magnetically coded actuator.
- Housing/Fixing
- Industry standard, wide body
- Contacts
- Up to 3 N/C or 2 N/C + 1 N/O
- Sensing Distance
- Wide 10mm operation
- Connection
- Pre-Wired or M12 8-Pole Quick Connect
- Indication
- Single Colour LED – Green when door closed
- Switching capability
- 0.2A (Requires 24Vdc supply to operate)
LED located on the top of the switch.
Informații privind UL508
Type 1 Enclosures. Maximum temperature: 50ºC plastic versions, 70ºC S/Steel versions. Maximum output 24V.dc 100mA. Powered by Class 2 or equivalent.
Datele tehnice provin din documentația producătorului. Pentru dimensionarea funcției de siguranță consultați fișa tehnică oficială.
| Cod produs | Descriere |
|---|---|
| 112013 | WPC 2M 2NC with LED |
| 112014 | WPC 5M 2NC with LED |
| 112015 | WPC 10M 2NC with LED |
| 112016 | WPC QC-M12 8way 2NC with LED |
| 112017 | WPC 2M 2NC 1NO with LED |
| 112018 | WPC 5M 2NC 1NO with LED |
| 112019 | WPC 10M 2NC 1NO with LED |
| 112020 | WPC QC-M12 8way 2NC 1NO with LED |
| 112105 | WPC 2M 3NC with LED |
| 112106 | WPC 5M 3NC with LED |
| 112107 | WPC 10M 3NC with LED |
| 112108 | WPC QC-M12 8way 3NC with LED |
