MGL-3P
Electromagnetic RFID Safety Switch 1000N
The MGL-3P is a magnetic guard locking safety switch with coded RFID technology, developed to deliver high functional safety and reliable electromagnetic guard interlocking in industrial applications. Housed in a high-specification polyester enclosure and fitted with a QC-M12 connector for fast, simple installation, it is ideal for machine guarding systems that require secure guard monitoring and a high degree of tamper resistance.
Standards
ISO14119 EN60947-5-3 EN60204-1 ISO13849-1 UL508
Informații privind UL508
Type 1 Enclosures. Maximum temperature 40ºC. Maximum output 24V.dc 200mA. Powered by Class 2 or equivalent.
Note
When the product is used deviant from these assumptions (different load, operating frequency, etc.) the values have to be adjusted accordingly.
Technical data is taken from the manufacturer's documentation. For safety function sizing, please consult the official data sheet.
| Cod produs | Descriere | Coding Type |
|---|---|---|
| 467006 | MGL-3P-M QC-M12 8way | Master Coded (can be re-taught) |
| 467003 | MGL-3P-U QC-M12 8way | Uniquely Coded (cannot be re-taught) |
| 467102 | MGL-3P Replacement Actuator | Master Coded Only |
