UGB-NET-CS-SS-LH-TK
Left-Hand, 4 Control Stations, Trapped Key, Stainless Steel
UGB-NET Gate Box with Integrated Ethernet/IP with CIP Safety combines high level RFID coded interlocking and machine control functions in one heavy duty housing. The compact design is less than 250mm long (10 inches) and 115mm (4.5 inches), suitable for integration onto access doors and hatches.
Safety functions
Guard interlocking Complies with the requirements of IEC 60947-5-3. Type 4 device with high coding acc. to ISO 14119.
Guard locking With lock monitoring for person and process protection.
Emergency stop.
Technical data is taken from the manufacturer's documentation. For safety function sizing, please consult the official data sheet.
Glisați lateral pentru a vedea tot tabelul
| Cod produs | Descriere | Deblocare manuală | Eliberare din spate | Orientare | |||||
|---|---|---|---|---|---|---|---|---|---|
| 529115 | UGB-NET-CS-SS-TK | Yes | No | Left-Hand | 529111 | UGB-NET-CS-SS-TK | No | No | Left-Hand |
| 529111 | UGB-NET-CS-SS-TK | No | No | Left-Hand |
